Information Technology has always been a fundamental part of Larsen
Design. Switching from manual drafting to Computer Aided Drafting in 1990 was a
milestone in the development of Larsen design. In 1991 Larsen Design purchased
a sophisticated space frame program. This program has since been updated and
has successfully been used on many projects such as bridges buildings and other
major structures. It is considered paramount to use the latest state-of-the-art
design programs available on the market.
In addition to the commercially available design software packages on
the market Larsen Design writes it own software applications for specific
projects. Our in-house programs cover both Design Drafting and Engineering
Applications.
Larsen Design has recently converted hundred percent to digital filing
for both design and administration. Our old manual filing system was gradually
over the years changed to an electronic system and has now completely been
replaced with our present electronic filing system.
|
|
|
|
|
|
|
|
|
|
|
|
 |
|
|
Left:
The hinged pole shown in a sloping
position.
The mast is being lowered to change
the light.
Right:
The hinged pole shown in upright
position.
|
|
|
|
|
|
25metre hinged lighting pole M4
Freeway – State wide Roads
Client: Lysaght Civil Product
Consulting Engineers: Larsen Design
Larsen design was appointed to design and produce shop
drawings for the hinged type poles
for street and flood lighting.
Larsen Design developed its own structural
design software for this application. In addition Larsen Design developed
its own drafting software in order to balance the mast and automatically
produce cutting sheets for fabrication in the workshop.
|
|
|
GO TO INDEX
Timber Design Program Developed by Larsen Design
On the
left is shown an Input page of our Timber Design program.
In
order to simplify the design of in-house projects this program was developed
to design timber structures in
accordance with The Australian Timber Structures code – Australian Standard AS 1720.1
The
program is written in the Visual Basic Programming Language
|
|
